This is a bolt-on fitment for the turbochargers as a fitted factory to the VR38 3.8 Liter Twin Turbo Powered Nissan GT-R R35 from 2007 – 2021.

Turbosmart Upgraded Wastegate Actuators have been developed to provide the maximum possible boost response for your factory frame turbocharger. The Turbosmart IWG75 Series of upgraded Actuators benefit from an increased ‘Working Ratio’ over the factory equipment, resulting in improved boost response throughout the RPM range.

This Improved ‘working ratio’ is achieved through an increase to the effective surface area of the diaphragm and revisions to the actual springs fitted, resulting in greater leverage of the forces the actuator is working against (boost and backpressure) while still being super-responsive.

Upgrading with the same base pressure as the factory, you can expect a broader boost and torque curve through peak boost achieved earlier in the RPM and hold longer into higher RPM. These improvements can be amplified with higher base pressures. However, tuning & recalibration is likely required.

Available In

  • 7psi / 0.50 bar: TS-0615-2072
  • 19psi / 1.31 bar TS-0615-2192
  • 24psi / 1.65 bar: TS-0615-2242
  • Proprietary Silicon Nomex Diaphragm
  • Choice of Springs from 3psi to 26psi (Optional)
  • High-Grade Billet Aluminum Construction
  • Stainless Steel Rods and Clevis
  • Turbosmart Unique Locking Collar System
  • Adjustable Base Pressure: Adjustable
SKU 290-000235
Brand Turbosmart
Shipping Weight 1.0430kg
Shipping Width 0.080m
Shipping Height 0.090m
Shipping Length 0.285m
Shipping Cubic 0.002052000m3
Type Aftermarket
Model # TS-0615-VR38--
